The belt conveyor equipped with frequency converter, which can effectively control material conveying speed.
The feeding machine is a forced feeder, which has the characteristics of uniform feeding, good continuous performance, simple operation and labor saving.
 |
|
|
|
I'm Online Chat Now
Certification
Pe Plastic Pelletizing Line For Waste Agriculture Film
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Plastic Processed: | HDPE, HDPE/PP, PE/PP, Lldpe, ABS/PP, PP, MLLDPE, LDPE | Condition: | New |
|---|---|---|---|
| Output (kg/h): | 500 - 1000 Kg/h | Video Outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Marketing Type: | New Product 2020 |
| Warranty Of Core Components: | 1 Year | Core Components: | Gearbox, Motor |
| Place Of Origin: | Shandong, China | Brand Name: | Xixin |
| Type: | Granulating Production Line | Screw Design: | Single |
| Voltage: | Customized | Weight: | 10 |
| Warranty: | 1 Year | Showroom Location: | None |
| Applicable Industries: | Manufacturing Plant, Other | Material: | PP/PE |
| Final Product: | Clean PP PE Pelletes | Pelletizing Type: | Water Cooling Strand Cutting |
| Color: | Customised | Max. Capacity: | 1000kg/h |
Plastic granulator machine ,we have kinds of granulator machine .please tell me your raw material and the capacity you want .l recommend for you.
♥STAND CUTTING PLASTIC GRANULATING EXTRUSION LINE♥
Stand Cutting Plastic Granulating Extrusion Line, is with double exhausting recycling unit. The line is mature product. it's widely used to recycling Low density polyethylene(LDPE), High polyethylene, Polypropylene(PP ),Polystyrene(PS)and ABS.
|
Model
|
Screw Diameter
(mm)
|
Power
(KW)
|
Capacity
(24h)
|
|
210
|
210/190/190
|
75
|
10-12t
|
|
240
|
240/220/220
|
90
|
12-14t
|
|
260
|
260/220/220
|
110
|
14-16t
|
|
280
|
280/230/230
|
132
|
16-18t
|
|
300
|
300/250/240
|
200
|
18-20t
|
Plastic Pelletizing Machine
This machine is used for granulation after the soft material of PP PE HDPE film woven bag is crushed and washed. It adopts a three-stage structure to achieve the purpose of multi-layer filtration.achieve the double filter to remove impurities to more effective material, and can fully exhaust, make plastic more uniform, particle plump and tough, shiny.
It is suitable for the cooling equipment in the process of plastic granulation production line, so that the important equipment for the normal operation of the pelletizer, the cooling water needs to be circulated and cooled.
The vertical fan is suitable for the plastic granulator to pull out the strip, after cooling through the water tank, the product can be used to dry the auxiliary water.
The vertical fan is suitable for the plastic granulator to pull out the strip, after cooling through the water tank, the product can be used to dry the auxiliary water.
water ring
Suitable for PE water ring hot cut.Special seal design,
prevent leakage of material, make the granules full.
used for taking off the moisture of water ring hot cutting
.high capacity,high stability.
used for taking off the moisture of water ring hot cutting
.high capacity,high stability.
Plastic Granulator
it is used for cutting the plastic granules. It is suitable for plastics such as PC,PE, ABS, PR,PA, PVC,POM, PPR,PBT.
This plastic granulating line is suitable for plastic film and bag, woven bag, ton bag and other PP/PE soft plastic material.The final product is clean plastic granules.
Laizhou Xixin Machinery Co., Ltd. is located in Shandong Province. It integrates research and development, design, production and sales. It is a private enterprise specializing in the production of plastic machinery and has 25 years experience in plastic manufacturing. With excellent product quality and excellent corporate reputation, the products are exported to Europe,Africa,Southeast Asia, the Middle East, South America and other regions, and have been well received by customers.
We sincerely hope to cooperate with you. for win-win results, develop together and create brilliance together!
• Pre-sale: we given client the details technician offer, sign the sales contract etc
• In-sales: we supply the details layout, installation instruction, technician support for the clients
• After sales: we arrange engineer to install the machinery and training the workers for client
• We have 24hours team to solve the after sales problem
• We have free spare parts with the machine
• We supply long term spare parts for every customer
• We always up date the new technology to every customer
• In-sales: we supply the details layout, installation instruction, technician support for the clients
• After sales: we arrange engineer to install the machinery and training the workers for client
• We have 24hours team to solve the after sales problem
• We have free spare parts with the machine
• We supply long term spare parts for every customer
• We always up date the new technology to every customer
